CCS, BV, ABS Approved 600m3/h, 1200m3/h, 2400m3/h marine external fire fighting fifi system is the marine external fire fighting system (FIFI). It is a necessary fire fighting equipment for external fire fighting of rescue ships, fire fighting ships, and oilfield guard ships, tug boats, work boats, patrol ships, maritime police ships etc. It generates large flow and high pressure fire fighting water through fire pumps to supply fire-fighting water cannons for effective external fire fighting, and widely used in inland rivers, coastal ports as tugboats, full-time fireboats and offshore platform supply. It is a professional fire extinguishing system used to extinguish ship fires externally.

The FI-FI system is including following core components:

1. Fire pump ( It can be driven by independent diesel engine, for above 2400m3/h, we recommend to drive by main engine to save space)

2. Fire monitors (Remote control, 360 degree rotation, jet and fog spray type)

3. Control system

4. Foam propotioner (Optional)

5. Water curtain system (Optional) : The water curtain system flow capacity is calculated according to the protection area of the ships, it can protect the ship from the fire when it is fighting for the fires from the other vessels.

The fire pump sets is composed of fire pump and diesel engine / electric motor, they are installed on a same stainless steel base frame and then installed in the engine room of the ships which is lower than the water level. The fire monitors can be sea water monitor and sea water and foam monitor, they are usually installed on the decks and controlled through control panel in bridge or remote controller.

The FIFI System had passed the Certification of BV, ABS, CCS and DNV. It can be controlled in wheel house through the main panel, and also can be controlled remotely by wireless control unit . The function buttons on panel can be customerized too.

1. Stainless steel 304 and stainless steel 316L material for fifi system fire water monitor.

2. Bronze impeller and stainless steel shaft for fifi pumps

3. Manual operation, electric motor driven and hydraulic driven for fifi monitor.

4. Electric motor and diesel engine driven fifi water pumps for choosing.

5. CCS, BV, ABS, DNV-GL etc certificates for vessel application.

6. The maximum vertical throwing height of seawater fire monitor can reach 80m.

7. Water jet and fog type and flow rate adjustable for different requirements.

8. Side suction top outlet fifi pumps and end suction top outlet fire water pumps for different installation space.

9. 200m remote control distance without block.

10. 360^o horizontal rotation with limited switch for remote fifi water monitors.

Chongqing Gohi Marine Equipment Co., Ltd is professional in manufacturing glass fiber reinforced plastic lifeboat, totally enclosed lifeboat, fire resistant lifeboat, free fall lifeboat, rescue boat, fast rescue boat, rigid rescue boat, life rafts and the davits for the lifeboat and rescue boat.

Our factory covers more than 20000 square meters, the life boat and rescue boat workshop is about 3000 square meters, the lifeboat and rescue boat davit work shop is about 2100 square meters, and the life raft workshop is about 2400 square meters. We have the complete production, testing equipments. Our factory is ISO9001:2008 quality management system approved by China Classification Society. And the products are approved by China Classification Society(CCS), China Shipping Inspection Bureau(ZC), China Fishing Vessel Inspection Bureay(ZY), France Bureau Veritas(BV), Russia Register Of Shipping (RS). Our annual output for lifeboats and rescue boats is more than 200 sets.

At the same time, we supply  other marine equipment such as marine fire fighting equipment such as FiFi system, self contained breathing apparatus, emergency escape breathing device; marine environment protection equipment such as sewage treatment plant, oily water separator, ballast water management system, marine incinerator etc which are in accordance with IMO MEPC standards; marine deck equipment such as marine crane, marine davit, marine winch, marine windlass etc; marine mooring equipment such as marine anchor, anchor chain, chain stopper, towing hook, rope etc

We have been dedicated in the marine equipment for more than 10 years. And we proivde world wide after sales services for all the products.

All of the products are approved by the main class such as CCS, BV, ABS, DNV-GL, LR, RMRS, RINA, IRS, KR, NK, part products are approved by USCG.
