IACS Approved IMO MEPC.107(49) 15PPM Marine Bilge Separator

Ask Lasest Price
Brand Name :	GH
Model Number :	15PPM Marine Bilge Oily Water Separator
Certification :	CCS, BV, ABS, DNV-GL, EC, RMRS
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	600 Sets Per Month
Delivery Time :	5-20 Days

Add to Cart

Product Details
Company Profile

IACS Approved IMO MEPC.107(49) 15PPM Marine Bilge Separator

Marine Bilge Separator can treat the ship’s bilge water containing various fuel oils, extremely dense residual residues, and emulsion mixture configured with iron oxide and surfactant effectively. The treated water meets the IMO MEPC.107(49) resolution and can be discharged outboard directly without environmental pollution.

This device can be used to treat oily bilge water in order to make it reach the requirements of IMO.MEPC.107 (49) resolution, which is also called 15ppm bilge separator. It contains type approved 15ppm bilge water separator, 15ppm bilge alarm and Automatic shut down Device.

The device adopts the combination of 1st stage, cone plate gravity and coalesce separation; 2nd stage, fiber filter and 3rd stage, membrane permeation in order to make the treated bilge water to reach the requirements of discharge standard of the resolution of IMO MEPC.107 (49).

The bilge water comes into the 1st stage coalescer separator because of the suction of the Ration pump, that is in a vacuum negative pressure, and it effectively prevents the problem that the bilge water is difficult to be separated because of the emulsion caused by feed pump under pressure. The liquid coming out of Ration pump is adsorbed and filtered by the 2nd stage fiber filter, and then goes into the 3rd stage membrane to reach the discharge standard. There is a 15ppm bilge alarm in the ship cabin to measure the oil content of effluent. If it finds that the oil content of effluent is in an excess of limit, the oil content meter can make order to switch turn it into the 3rd stage, membrane treatment process. The oil content meter will give an alarm if finds the oil content of effluent is above limit, and the unqualified water pneumatic three‐way valve VS6 is opened automatically, so that the unqualified water is return to bilge, not to the overboard.

Type	YWC0.25	YWC0.5	YWC1.0	YWC1.5	YWC2.0	YWC2.5	YWC3.0	YWC4.0	YWC5.0
Rating/max capacity (M3/H)	0.25	0.5	1	1.5	2	2.5	3	4	5
Power of pump (KW)	0.37	0.55	0.75	1.1	1.1	1.5	1.5	2.2	2.2
Electric heater power(KW)	3	3	option	option	option	option	option	option	option
steam heater m2/kw	__	__	1/30	1/45	2/60	2/75	3/90	4/120	5/150
15ppm bilge alarm	included	included	included	included	included	included	included	included	included
base (channel steel)mm	#5 1000*600	#6 1100*690	#6 1050*1080	#6 1100*1130	#8 1900*1120	#8 1900*1120	#8 1700*1500	#8 2280*1700	#8 2590*2000
height(mm)	1250	1460	1600	1650	1700	1900	1900	1900	1900
dry/wet weight (kg)	300/450	600/800	800/860	1060/1810	1260/2260	1500/2800	1800/3200	2100/3900	2500/4600
applicable ship vessel	〈1000 DWT	1000~5000DWT	5~10 KDWT	10~30 KDWT	30~50 KDWT	50~100 KDWT	100~200 KDWT	100~300 KDWT	300 KDWT above

1. Compact design, easy maintenance and high efficiency process.
2. Special organic clay emulsion absorbing
3. High quality 15ppm bilge alarm unit secured reliable and accuracy discharge monitor.
4. Middle positioned processing pump to avoid emulsification.
5. Type approved 15ppm bilge separator, 15ppm bilge alarm and automatic shutdown device

IACS Approved IMO MEPC.107(49) 15PPM Marine Bilge Separator

IACS Approved IMO MEPC.107(49) 15PPM Marine Bilge Separator
